Product Code: GKB-1
GKB-1 is a multiply aluminium polyester laminated ducting with an en-capsulated high tensile steel wire helix.
Application: GKB-1 has been specially designed for the HVAC market.
Product Code: GKB-2
GKB-2 is a non-insulated aluminum flexible duct manufactured from 02 aluminum + polyester layers (ALU+PET) of 0.023 mm thick with an en-capsulated high tensile steel wire helix.
Application: GKB-2 has been specially designed for the HVAC market.
Product Code: GCTT
GCTT is closed tube structure, resilient, easy to bend and stretch. The tube is manu- factured from layer of glass fiber reinforced aluminum with flame retardant to enhance insulation and fire resistance, heat resistance up to 200°C.
Application: GCTT has been specially designed for the HVAC market.
Product Code: GCBT
GCBT consists of one of the GKB-1 weight innerducts, 25 mm thick fibreglass insulation- weight 16 / 24 / 32 kg/m3 and is covered with either a vapour barrier outerjacket or one of the (Alum + Scrim + PET) ducts. GCBT has been developed to minimise the heat gain or loss resulting from the temperature difference between the air flowing in a duct and the surrounding air. The vapour barrier prevents condensation forming on the outside of ducts carrying air at lower temperatures than the surrounding air.
Application:GCBT has been specially designed for the HVAC market.
Product Code: GAFS
Alu 1-layer: Spirally produced ducting of one layer of Aluminium Foil.
Application: Semirigid Flexible Duct is a bendable flexible ducting in aluminium. The GAFS products are being used for the HVAC market as well as for various industrial pur- poses.
Product Code: GCBOPL
GCBOPL is an insulated aluminumflexible duct manufactured from 02 aluminum with an en-capsulated high tensile steel wire helix,so it is elastic and flexible. The middle insulation layer is made of non-toxic polyester, the outside is coated with reinforced glass cloth that is not destroyed in normal conditions.
Application: GCBOPL has been specially designed for the HVAC market.
Product Code: GCBOKV
GCBOKV is an insulated flexible ductwith a copper coated and anti-virus layer that helps the air to be led through the pipe, always cleaned, never virus in the tube. In addition, the GCBOKV wind tunnel has an insulating cotton layer made from an absolutely safe, health-resistant cotton layer during construction and product users. This product meets the strict requirements of clean rooms and air condition- ing systems for intensive rooms in the health sector.
Application: GCBOKV has been specially designed for the HVAC market.
Product Code: NM1
Flexible duct connector is formed through fold repression by using fire-resistant fabric and punching sheet. With this technics,the gas tightness is good, the punching sheet is easy to be shaped, and the instalaation is convenient.
Product Code: NM2
Flexible duct connector is formed through fold repression by using fire-resistant fabric and punching sheet. With this technics,the gas tightness is good, the punching sheet is easy to be shaped, and the instalaation is convenient.
Description
The diffuser is used for supplying and returning air from different directions. It has disc-shaped blades with a fixed angle to effectively disperse the airflow.
Material & Finish
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Application: Suitable for direct mounting on ductwork or false ceilings.
Description:
The elliptical blade grille is often used as a supply or return air grille. It can be designed with a single or double layer of blades and can be easily removed for inspection and cleaning.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame and blades are made of extruded aluminum.
- The blades have a hook structure to block rainwater.
- Can be fitted with an optional dust filter or insect screen
Description:
The T-Bar grille is commonly used for return air applications in air conditioning and ventilation systems.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame is made of extruded aluminum.
- Blades are made of hollow T-shaped extruded aluminum.
- Can be fitted with an optional dust filter or insect screen.
Application: Commonly mounted directly on ductwork or false ceilings.
Description:
The grille has a separate frame and core, allowing for easy removal and maintenance. This grille type includes two main models: double frame with elliptical blades and double frame with T-blades.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame and blades are made of extruded aluminum.
- Available in square or rectangular shapes depending on the design.
Application: Mounted on ceiling panels or walls.
Description:
A product with high aesthetic appeal, featuring adjustable blades to control airflow in multiple directions.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame and blades are made of extruded aluminum.
- Categorized as 1-slot, 2-slot, 3-slot, etc., corresponding to the number of narrow slots.
Application: Suitable for spaces such as restaurants, meeting rooms, and conference halls.
Description:
The Z-blade louver is designed with layers of blades angled at 45 degrees, providing both protection and resistance against rainwater.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame is made of extruded aluminum.
- Blades are made of Z-shaped extruded aluminum for effective water shielding.
- Often installed with a dust filter or stainless steel mesh to prevent insects.
Application: Commonly installed outdoors.
Description:
The face of the grille consists of small, uniform square cells, with the ability to adjust the airflow direction as required.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame is made of extruded aluminum.
- The core is designed with interwoven thin aluminum strips at right angles.
- Can be equipped with a volume control damper or a dust filter.
Application: Used as a return or supply air grille, typically mounted on false ceilings or directly on ductwork.
Description:
Designed with small, evenly arranged holes to provide optimal and uniformly distributed airflow. This structure also helps to minimize external noise.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- The frame is made of extruded aluminum.
- The grille face is perforated.
- Can be equipped with an optional volume control damper or a dust filter.
Application: Commonly installed in cleanrooms.
Description:
The round diffuser is a type of multi-directional diffuser. Its disc-shaped blades with a fixed angle direct the airflow in various directions, providing optimal performance.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating
Construction & Features:
- Frame is made of extruded aluminum.
- Blades are made from a single stamped aluminum sheet.
- Can be equipped with an optional volume control damper, dust filter, or insect screen.
Description:
The frameless grille offers high aesthetic value because its frame is designed to be hidden within the plaster ceiling, without being exposed.
Material & Finish:
- Material: Extruded aluminum.
- Surface Finish: White powder coating.
Construction & Features:
- Frame is made of extruded aluminum.
- The blade deflection is approximately 15° and 30°.
- There are no fixed sizes; it is manufactured in various dimensions based on customer requirements.
Application: Commonly installed in projects such as castles, villas, high-end apartments, and showrooms.
